Led Driver 12v 24v AC to DC Slim Ultra Thin Switching Power Supply
Features:
1.Adjustable:Dimmable Power supply SMOOTH AND RELIABLE DIMMING from 0 to 100% with no flicker
2. Safety features: Automatic overload cut-off, over Voltage cut-off, automatic thermal cut-off, short circuit protection.
3.Widely used:Outdoor transformers are designed with landscape lighting in mind; featuring large wattage capacities and a rugged,weather-proof frame for LED Strip light, cabinet light, Puck Lights, Rigid Strip Light etc.
4.Strong and Durabl:Input and output yellow isolation waterproof and dustproof protection,the led 12V transformers are the best choice for outdoor landscape lighting.
5.Easy to use:No flicker design, good for eye protection, small size suitable for small space installation
Specification
| Output Power: | 150W MAX | Output Current: | 0-12.5A |
| Output Type: | Single | Dimmable ways: | touch time delay,triac,0-10v,PWM signal,resistance |
| Input Voltage: | 100-260V AC | Overload protection: | 110%~130% |
| Output Voltage: | 12V DC | Short circuit protection: | auto recovery |
| Output Frequency: | 47-63HZ | Overvoltage protection: | have |
| Working temperature: | -30℃~+60℃ | Cooling: | self cooling |
| Storage temperature: | -40℃~+80℃ | Warranty: | 2 years |
| Size: | 286*49*30mm | Efficiency: | ≥88% |
Superior Safety
Built-in safeguards to protect against over voltage, over current, overheat, short-circuit, which will provide ultimate
protection for you and your devices.
Premium Quality
The shell is made of aluminum. Cellular structure design can enhance air convection and speed up heat dissipation. Premium quality materials make it more solid and durable.
±15%Voltage Adjustment
The output voltage can be regulated by ±15%, which greatly expand its application range. It can supply with any current your device draws.
Adjustable
Dimmable Power supply SMOOTH AND RELIABLE DIMMING from 0 to 100% with no flicker
Stable Output
Built-in advanced synchronous rectifier smart chip and EMI filter, convert fluctuating voltage to stable voltage, effectively reduce electromagnetic interference.
Widely used
Great for LED Strips, 3D Printer, ham radio transceiver, CCTV cameras, audio amplifier, wireless router, ADSL Cats,
HUB,audio/video power supply.
FAQ
Q1. How can I obtain a sample?
A: Contact us and we will handle it.
Q2. Can I add my own logo?
A: Sure, we offer flexible OEM & ODM solutions. You can have your logo on the product, packaging, user manual, you name it.
Q3. What is your MOQ?
A: None.
Q4. What is the production lead time?
A: We keep a ready to ship stock level on certain product lines, others usually take 2-4 weeks.
Q5. What is the delivery time?
A: We offer shipping via sea, road, rail and air. The shipment time depends on the choice of transportation.
Q6. What is the warranty?
A: We offer a minimum two years warranty along with a comprehensive after sale service.
Q7. Are the products certified?
A: Yes, we are fully certified for the EU and UK markets. If you require any other forms of certificates, do get in touch.
Q8. Are you a manufacturer?
A: For our involvement in the production line process, we may as well be. Do feel free to pay us a visit at any time.
